Type 06.0.00.110. …
| Technical data | |
|---|---|
| Function | single-acting with spring return |
| Ambient temperature | max. 80° C |
| Connection 1 | R 1/8″ |
| Connection 2 | R 1/8″ |
| Piston diameter | 110 mm |
| Cylinder power | 850 N max. |
| Stroke | 20 mm |
| Operating pressure | vacuum max. 99,9 % |
| Securing | with 4 screws M 6 |
| Piston rod | through-going or one-sided |
